Product description: hvac 1 fuse solar water heating with tank
1. Air Heat Pump double water connections is possible.
2. Low Noise Heat Pump, quiet running due to high quality fan.
3. Long lasting antirust stainless steel cabinet design, adopt hi-tech double wall tubing heat exchanger
and seperate all necessary unit parts from the water, more safety and repairable.
4. Residential Heat Pump water heater running ambient temperature: -7 ~ 40°C, can reach -10~40 ℃
by adding extra heating elements.
5. CE, CB approval All In One Heat Pump water heater.
6. All in one heat pump waterproof controller cover is optional.
7. Customized design for tank or pressure valve or element is welcome.
Product detail:
| Model |
| ZR9W-300TE |
| Rated heating capacity | kw | 3.0 |
| Btu | 10000 |
| Water tank volume | L | 300 |
| COP |
| 3.3 |
| Heating power input | kw | 0.9 |
| Power supply | V/Ph/Hz | 220~240/1/50 |
| Max outlet water temp | ℃ | 60 |
| Applicable ambient temp | ℃ | -7~43 |
| Duct diameter | φ | 150 |
| Rated running current | A | 4.2 |
| Auxiliary electrical heating | kw | 1~2 |
| Noise | dB(A) | 49 |
| Air volume | m³/h | 700 |
| Rated tank pressure | Mpa | 0.6 |
| Water connections | Inch | 3/4" |
Schematic:
Product application:
Looking for ideal Trane Ceiling Mounted Air Handler Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Ac Unit Hvac are quality guaranteed. We are China Origin Factory of Keith's Heating and Air. If you have any question, please feel free to contact us.
Product Categories : All In One Heat Pump
